Power (0.5 – 19.7 GHz)
MCLI offers fast switching solutions through its pin diode switch product line. A diverse range of multiport models are currently accessible in the market, extending up to SP8T (Single Pole 8 Throw), that offer distinguished characteristics such as high isolation, low insertion loss, and rapid switching times of up to 100 nanoseconds. The absorptive models are equipped with 50-ohm terminations at each of their output ports to ensure a low voltage standing wave ratio (VSWR) in both the on and off states. Reflective models perform the function of conducting RF power in a reverse-biased diode configuration and reflecting RF power in a forward-biased switch configuration.
Absorptive and Reflective Models
100 Nanoseconds Switching Speed
Low Loss, Low VSWR, Compact Size
Browse all Power (0.5 – 19.7 GHz)
Filters
Gain Min. (dB)
Gain Flatness (±dB)
VSWR In/Out
Power VDC
Showing all 30 results
| Part # | Frequency Range (GHz) | Gain Min. (dB) | Gain Flatness (±dB) | VSWR In/Out | Power VDC | Lead Time | Notes | Action | |
|---|---|---|---|---|---|---|---|---|---|
| Min | Max | ||||||||
| PA-96 | 0.005 | 1 | 14 | 1 | 2.00:1 | 15 | 6-7 Weeks | N/A | Request Quote |
| PA-97 | 0.005 | 1 | 27 | 1 | 2.00:1 | 15 | 6-7 Weeks | N/A | Request Quote |
| PA-98 | 0.005 | 1 | 28 | 1 | 2.00:1 | 15 | 6-7 Weeks | N/A | Request Quote |
| PA-99 | 0.005 | 1 | 13 | 1 | 2.20:1 | 13 | 6-7 Weeks | N/A | Request Quote |
| PA-1 | 0.5 | 0.8 | 20 | 1 | 2.00:1 | 28 | 6-7 Weeks | N/A | Request Quote |
| PA-1/8W | 0.5 | 0.8 | 20 | 1 | 2.00:1 | 28 | 6-7 Weeks | N/A | Request Quote |
| PA-26-20 | 0.5 | 6 | 20 | 2 | 2.00:1 | 12 | 6-7 Weeks | N/A | Request Quote |
| PA-2 | 0.8 | 1 | 20 | 1 | 1.50:1/2.00:1 | 28 | 6-7 Weeks | N/A | Request Quote |
| PA-118-20 | 1 | 18 | 21 | 2 | 2.00:1 | 12 | 6-7 Weeks | N/A | Request Quote |
| PA-3 | 1.5 | 1.7 | 30 | 1 | 1.50:1/2.00:1 | 12 | 6-7 Weeks | N/A | Request Quote |
| PA-20-45 | 2 | 2.2 | 45 | 0.5 | 2.00:1 | 15 | 6-7 Weeks | N/A | Request Quote |
| PA-25-35 | 2 | 2.5 | 35 | 0.5 | 2.00:1 | 15 | 6-7 Weeks | N/A | Request Quote |
| PA-25-42 | 2 | 2.5 | 42 | 0.75 | 2.00:1 | 15 | 6-7 Weeks | N/A | Request Quote |
| PA-24-45 | 2.1 | 2.3 | 45 | 0.5 | 2.00:1 | 15 | 6-7 Weeks | N/A | Request Quote |
| PA-6 | 3.6 | 4.2 | 36 | 0.5 | 1.50:1 | 12 | 6-7 Weeks | N/A | Request Quote |
| PA-7 | 5.925 | 6.425 | 47 | 0.5 | 1.50:1 | 12 | 6-7 Weeks | N/A | Request Quote |
| PA-35-40 | 6 | 18 | 40 | 2 | 2.00:1 | 0.8 | 6-7 Weeks | N/A | Request Quote |
| PA-32 | 7 | 12 | 23 | 0.8 | 1.50:1 | 15 | 6-7 Weeks | N/A | Request Quote |
| PA-8 | 7.125 | 7.725 | 35 | 1 | 1.50:1/2.00:1 | 12 | 6-7 Weeks | N/A | Request Quote |
| PA-818-20 | 8 | 18 | 14 | 1.5 | 2.00:1 | 12 | 6-7 Weeks | N/A | Request Quote |
| PA-27-25 | 9 | 11 | 25 | 1 | 2.00:1 | 15 | 6-7 Weeks | N/A | Request Quote |
| PA-19 | 10 | 11 | 27 | 1 | 2.00:1 | 15 | 6-7 Weeks | N/A | Request Quote |
| PA-9 | 10.7 | 11.7 | 20 | 1 | 1.50:1/2.00:1 | 12 | 6-7 Weeks | N/A | Request Quote |
| PA-48 | 11.7 | 12.7 | 55 | 1 | 2.00:1 | 12 | 6-7 Weeks | N/A | Request Quote |
| PA-36 | 12 | 18 | 26 | 0.8 | 1.50:1 | 15 | 6-7 Weeks | N/A | Request Quote |
| PA-10 | 12.7 | 13.25 | 15 | 1 | 1.50:1/2.00:1 | 12 | 6-7 Weeks | N/A | Request Quote |
| PA-11 | 14 | 14.5 | 15 | 1 | 1.50:1 | 12 | 6-7 Weeks | N/A | Request Quote |
| PA-12 | 17.7 | 18.2 | 15 | 1 | 1.50:1 | 12 | 6-7 Weeks | N/A | Request Quote |
| PA-13 | 18.1 | 18.6 | 45 | 1 | 1.50:1 | 12 | 6-7 Weeks | N/A | Request Quote |
| PA-14 | 19.2 | 19.7 | 15 | 1 | 1.50:1 | 12 | 6-7 Weeks | N/A | Request Quote |
